MERCURY

Semi-automatic case sealing machine with manual adjustment for water-activated tape and adhesive tape

The Mercury case sealer is designed to support water-activated tape sealing units and allows them to be interchangeable with any adhesive tape sealing unit available on the market, offering — for the first time ever — a connection point between the world of water-activated tape and adhesive tape.

BOX DIMENSIONS:
Length min. 150 mm – max. ∞
Width min. 120 mm – max. 600 mm
Height min. 90 mm – max. 600 mm

TECHNICAL DATA:
Side drive belts for box conveying
Manual box size adjustment
Compact* taping head
Power supply: 230 V P+N+PE
Installed power: 1 kW
Electrical protection: IP54
Operating temperature: +10°C to max. +40°C
Humidity: 40% – 65%
Belt speed: 20 m/min
Production capacity: approx. 14 boxes per minute
Working table height: 650 mm
RAL 7015 fixed parts – 5021 moving parts
Weight: 250 kg
Machine dimensions (L x W x H): 1686 x 1065 x 1860 mm ± 50 mm
