GEM 535

The semi-automatic single format taping machine mod. GEM 535 with lower lateral and upper horizontal drive belts is specifically designed for the lower and upper adhesive tape taping of tall American boxes with narrow bottoms, providing considerable stability to the box during closing.

BOX DIMENSIONS

- Length min. mm 150 max. mm ∞

- Width min. mm 100 max. mm 500

- Height min. mm 100 max. mm 500

TECHNICAL DATA:

Lower lateral and upper horizontal drive belts H = 50 mm
Manual box size adjustment
Upper and Lower Taping Heads
Standard configuration T22 / T23 - tape width from 38 to 50 mm
Tape width from 25 to 50 mm depending on the Head (to be decided when ordering)
Tape tension Adjustable
Max tape reel diameter 360 mm
Internal reel diameter 76 mm
Electrical power supply 400 V three-phase - 50/60 Hertz
Installed power 0.25 Kw
Electrical protection IP 54
Operating temperature + 5° C - max. +35° C
Belt speed 22 m/min
Production 1000 boxes/h
Work surface height 650 mm
Weight 144 Kg
Machine dimensions (L x W x H) mm. 1,170 x 880 x 1,450

RAL: 7015 Fixed parts, 6029 moving parts
