GEM X520

BOX DIMENSIONS

- Length min. mm 200 max. mm ∞

- Width min. mm 100 max. mm 500

- Height min. mm 100 max. mm 500

TECHNICAL DATA

Box drive belts Lateral H = 50 mm
Box size adjustment Self-dimensioning
Top and Bottom Taping Heads
Standard configuration T22 / T23 - tape width from 38 to 50 mm
Max tape reel diameter 360 mm
Internal reel diameter 76 mm
Electrical power supply 400 V three-phase - 50/60 Hertz
Installed power 0.25 kW
Electrical protection IP 54
Operating temperature + 5° C - max. +35° C
Belt speed 22 m/min
Production 300/500 boxes/h
Operating pneumatic pressure 6 bar
Air consumption per cycle 11 nl
Working surface height 650 mm
Machine dimensions (L x W x H) mm. 1,162 x 1,013 x 1,782

RAL: 7015 Fixed parts, 6029 moving parts

Sheet metal side protections with access door, upper cover
Lower protections for drive belts
