GEM F470G

Automatic taping machine GEM F470G is a model equipped with a system for floating the upper carriage that has several advantages:

- overfilled boxes can be taped without problems

- floating on hard cardboard facilitates the closing of the side flaps

- with the floating system it is possible to raise the upper head group to the maximum limit to replace the tape in the lower head, using the floating cylinders. Once the operation is finished, the cylinders return to their original position and it is no longer necessary to adjust the height of the upper taping group.

Product dimensions:

min L. 220mm W. 100 mm H. 100 mm

max L.600 mm W. 500mm H. 650 mm

TECHNICAL DATA

Side box conveyor belts H = 50 mm
Auto-dimensioning box size adjustment
Upper and Lower Taping Heads
Standard configuration T22 / T23 - tape width from 38 to 50 mm
Max tape reel diameter 360 mm
Internal reel diameter 76 mm
Electrical power supply 400 V three-phase - 50/60 Hertz
Installed power 1 kW
Electrical protection IP 54
Operating temperature + 5° C - max. +35° C
Belt speed 22 m/min
Production 300/500 boxes/h
Operating pneumatic pressure 6 bar
Air consumption per cycle 2.5 nl
Work surface height 650 mm

Weight 293 kg
Machine dimensions (L x W x H) mm. 1,820 x 990 x 1,782

Side sheet metal protections with access door, upper cover
Lower drive belt protections

RAL: 7015 Fixed parts, 6029 moving parts
