Mytho Station
Automatic pallet wrapper with rotating table
rotary plate diameter 1800 mm Roller height from the ground 190/200 mm
maximum load weight 1500 kg
maximum load dimensions 1000x1200 mm roller conveyor width 1100 mm
wrapping height 2400 mm
start and stop of gradual regulation
roll-holder trolley ascent speed adjustable by inverter
rotation stop at the end of the cycle in phase for load collection
photocell for reading pallet height
Siemens 1200 machine control PLC
6" color touch screen panel
possibility to memorize the wrapping cycles
table speed regulation by inverter
roll-holder trolley with mechanical brake
pneumatic film holding clamp
pneumatically operated cutting system with hot cutting wire
on-board motorized roller conveyor for the transit of pallets to be wrapped and unloaded
standard voltage 400 V-1PH + N + PE 50/60 hz
installed power 1.5 kw
compressed air consumption 50 liters per cycle
