Reggiatrice PT702 B
Technical features
Bow size 650 mm. (W) 500 mm. (H)
Different bow sizes (see relevant table)
Minimum pack size (W = 120 mm.) (H = 20 mm.)
Parameter programming via digital display
Lexan side protections that can be opened laterally (optional)
Worktop with motorized belts, adjustable speed from 10 to 60 m/min
Automatic strap insertion and relaunch
Steel bench with motorized belts
N° 4 swivel wheels with parking brake and adjustable feet
Worktop height adjustable from 800 to 900 mm (750 mm on request)
N° 1 control photocell to automatically perform 0 to N parallel ties, programmable via digital display
Strap cooling time control
Electronic tensioning force control
Control of the optimal welding temperature via potentiometer
Min. tensioning 1 Kg. max. 35 Kg. (45 Kg. only with 12 mm strap)
BRUSHLESS type strapping cycle motors
Usable strap width: 5,6,9, 12 mm. (via conversion kit)
Internal diameter of strap reel: 200 mm
Power supply 230 V 50 Hz
Strapping speed: up to 65 strokes per minute
