PT 601B
Technical features
Standard arch size 850 mm. (w) 600 mm. (h)
Different arch sizes (see relevant table)
Packs (W=200-800 mm.) (H=30-550 mm.)
(L=250 min.) max 35 Kg
Automatic insertion and relaunching of the strap
Nox steel bench with motorized belts (speed 30 m/min)
N° 2 adjustable package stop photocells for n° 0 - N parallel strapping
N° 4 swivel wheels and adjustable feet
Electronic tensioning force control,
Tensioning min. 10 Kg. max. 70 Kg.
Adjustment of strap welding cooling time via timer
Adjustment of welding blade temperature via 6-position selector
Usable strap width: 9, 12 mm. (via conversion kit)
Internal diameter of usable strapping reel: 200, 280 mm
Power supply 400 V 50 Hz
Net weight of strapping machine 330 Kg.
Strapping speed: 2.2 seconds/cycle (max 10 packages with 2 ties each)
