Automatic strapping PT 702 12

Technical features

Standard arch size 650 mm. 500 mm. (h)
Different arch sizes (see relevant table)
Pack sizes (W = 100-600 mm.) (H = 30-450 mm.)
External reel holder
Function control panel positioned in front of the machine
Automatic strap insertion and relaunch
Stainless steel bench
N° 4 swivel wheels with parking brake
height adjustable from 820 to 920 mm
Electronic tensioning force control
Tensioning min. 1 Kg. max. 45 Kg.
BRUSHLESS type strapping cycle motors
Control of the optimal welding temperature via potentiometer
Control of the strap cooling time
Usable strap width: 12 mm.
Inner diameter of strapping reel: 200 mm
Power supply 230 V 50 Hz
Strapping speed: up to 65 strappings per minute
