ROBOT MONOBLOCCO PS 300
4-stage monoblock robot suitable for production using one or two different products; You can palletize the most varied products (scatole, sacchi, drums and others) thanks to the press clamps made to measure for any application.
It can also be used as a roller conveyor, catenary and automatic pallet magazine for automatic feeding of empty pallets and automatic evacuation of empty pallets.
Machine management and the implementation of work programs (formats) are extremely simple and, after cleaning installation, the presence of the manufacturer's technicians is not required.
Technical data
Pallet-tizzabile products: buckets, bags, drums and others
Power supply: 380Vac - 50 Hz
System: 3 phase + N + PE
Installed power: 11 kw
Operator interface: Touch screen 5.7"
Maximum speed: up to 600 cycles/hour
Maximum number of Previous points: 1
Maximum number of pallet posts: 1
Maximum weight of product in clamp: 50 kg
Maximum number of programmable formats: 36 (in the basic version)
Maximum pallet dimensions that can be realized: **** x 1300 x 2900 mm
Accessories: automatic feeding, automatic evacuation , pallet clamp, skirt clamp, double pallet, industrial pc
