- confezionatrice Angolare PT600 CS
confezionatrice Angolare PT600 CS
MACHINE DESCRIPTION
Fully electric automatic angular packaging machine
Machine with automatic sealing system
Sealing blade with PTFE treatment
Control system equipped with 4.3" graphic LCD control panel
Digital and analog in/out control modules
20 storable work cycles
Sealing temperature regulated by microprocessor
Automatic control of sealing bar height
Possibility of packaging single packs or product groups
Adjustable conveyor belt speed
Safety device
Control of incoming packaging packs
Control statistics on board: piece counter; product length detection; instantaneous production; machine performance
TECHNICAL DATA
Power supply voltage 380-415 Volt 3 PH+N-PE 50/60 HZ
Installed power 3350 W
Sealing bar dimensions 640x510 mm
Maximum product height 200 mm
Production up to 3600 packs per hour
Conveyor belt speed from 10 to 30m/min
Maximum reel dimensions: external diameter 350; length 600mm
MACHINE DIMENSIONS
with trolley mm 2175x1875x1505-1665H
MACHINE OPERATING TEMPERATURE
From + 8° to + 40° -
Max. relative humidity 70%
Machine in accordance with CE
