Pack Point 08

BOX DIMENSIONS:

Length min. mm 160 max. mm 650
Width min. mm 140 max. mm 500
Height min. mm 100 max. mm 020

TECHNICAL DATA:

Pneumatic operating pressure 5 bar
Air consumption per cycle 7.5 nl
Using temperatures + 5° C - max. +35° C
Work surface height 650 mm
Weight 125 Kg
Machine dimensions (L x W x H) mm. 1,240 x 805 x 868
RAL 7015 fixed parts, 6029 moving parts
