F2000

B

SIZES:

- Length min. mm 220 max. mm 600

- Min. length mm 100 max. mm 500

- Height min mm 100 max mm 500

TECHNICAL DATA:

Output 840 trays/hour (with length function)
Dedicated control and control panel Touch Screen Kyte 7'' color
Magazine capacity 110/120 trays with the possibility of applying magazines extra, see possible models Optional

Voltage V400/50Hz
Protection IP 54
Pneumatic exercise pressure 6 bar
Air consumption per cycle 13 nl
Venturi vacuum system - 25m3 /h 700mm HG
Using temperature + 5° C - max. +35° C
Working surface height * mm. 650 + 30
Weight 490 Kg
Machine dimensions (L x W x H) mm. 1,532 x 2,110 x 1,800

RAL 7015 part fixed, 6029 part mobile

Safety protections: upper and lower cover; protection of soffit on side magazine
