Lybra Station
Automatic rotating arm machine
TECHNICAL DATA
MAXIMUM PALLET DIMENSIONS 1200 x 1200 MM
MAXIMUM PALLET HEIGHT 2500 MM
PHOTOCELL FOR LOAD HEIGHT DETECTION OR WITH ALTIMETER
ROTATION WITH GEAR AND HIGH RESISTANCE BEARING
ARM ACCELERATION AND DECELERATION WITH INVERTER
ADJUSTABLE REEL CARRIAGE UP AND DOWN SPEED WITH INVERTER
ACOUSTIC SIGNAL FOR AUTOMATIC CYCLE START
EMERGENCY AND RESET BUTTON AS PER CE STANDARDS
FILM CONSUMPTION CALCULATION (ONLY ON PRS & PS CARRIAGES)
SIEMENS 1200 MACHINE CONTROL PLC
6” COLOUR PRO FACE TOUCH SCREEN PANEL
POSSIBILITY OF STORE THE WINDING CYCLES
FE TYPE REEL HOLDER WITH ADJUSTMENT FROM Q.E
PNEUMATIC FILM HOLDING CLAMP
PNEUMATICALLY ACTIVATED CUTTING SYSTEM WITH HOT CUTTING WIRE
STANDARD VOLTAGE 400 V-1Ph + N + PE 50 /60 Hz
INSTALLED POWER: 1.5 KW
COMPRESSED AIR CONSUMPTION 50 LITERS PER CYCLE
